  • High grade gray casting machine body design through The Finite Element Method (FEA) analysis to keep light-weighted structure advantages while ensuring high machine rigidity.
  • All rail mounting surfaces through milling and grinding to ensure excellent precision and contact rates above 90%.
  • All joint surfaces of the machine body though manually scraped to ensure geometric accuracy and contact rigidity.
  • Special large span structure of the machine base and column, is able to bear high inertia gravity and improve dynamic responsiveness of the whole machine.
  • V1 vibration standard of BBT40 direct drive spindle, compared with most popular V4 vibration standard, has smaller spindle vibration and better surface processing performance.
:
Share:

High precision and high efficiency series.

High speed high precision VMC for molds processing
utilizes its mature vertical machining centers techniques to present you with the BF-650V, which is special design for the industries in 3C component machining and small die-&-mold machining, it can continuously complete drilling, milling, tapping, boring, reaming and other machining processes by once clamping, and can complete coordinate boring and fine machining of complicated parts and molds accurately and efficiently. BF-650V is broadly used in high precision parts and molds manufacturers, can fully present high precision and high efficiency machining ability at a very reasonable cost.

vertical machining centers

Parameter Unit 650V
X/Y/Z axis travel mm 650*500*500
Table size mm 720*450
T slot mm 5-18*90
Max load on table kg 400
Spindle center to column mm 480
Spindle nose to table mm 150-600
X/Y/Z axis motor KW 2.0/2.0/3.0
X/Y/Z rapid feed m/min 30/30/30
Controller   Mitsubishi M80A/M80B Fanuc: 0i-MF/Siemens 828D
Spindle taper   BBT40-Φ120
Spindle speed rpm 12000
Spindle motor HP 11
Positioning accuracy mm ±0.003/300
Repeated accuracy mm ±0.002/300
Air pressure kg/cm² 6~7bar
Dimension mm 2200*2780*2730
Weight kg 4500
